NXP Semiconductors

MPX10D

Name: MPX10D
Brand: NXP Semiconductors
SKU: 54-MPX10D
Availability: InStock
Rating: 4.9 (3 reviews)

Sensors

Manufacturer NXP Semiconductors

Mfr. Part #: MPX10D

Apmheo Part #: 54-MPX10D

Datasheet:

NXP Semiconductors-MPX10D-datasheets-731210.pdf

Description: SENSOR 1.45PSID .035V

In Stock : 122

Need wholesale pricing? Send RFQ now for the best rates and immediate response.

QUICK RFQ

ADD TO RFQ LIST

Quantity

Unit Price

Ext. Price

1+
$11.81080
$11.81

10+
$10.17024
$101.7

100+
$9.51412
$951.41

1000+
$9.02201
$9022.01

ADD TO CART

QUICK ORDER

Unit Price： $11.81080 Subtotal： $11.81

Operating Pressure

1.45PSI (10kPa)

Unit Weight

0.056715 oz

Device Pressure Type

Differential

PPAP

No

Pressure Type

Differential

Product Status

Active

RoHS

RoHS Compliant

Automotive

No

Port Type

No Port

Supplier Package

Case 344C-01

Package / Case

4-SIP Module

Voltage - Supply

3V ~ 6V

REACH Status

REACH Unaffected

Response Time (ms)

1

Maximum Operating Supply Voltage (V)

6

EU RoHS

Compliant

Moisture Sensitivity Level (MSL)

Not Applicable

Operating Temperature

-40°C ~ 125°C

Termination Style

PC Pin

Port Size

-

Media

Air

ECCN

EAR99

Mounting Type

Through Hole

Operating Pressure Range

0kPa to 10kPa

Pin Count

4

Mounting

Through Hole

Typical Operating Supply Voltage (V)

3

HTSUS

8542.31.0001

Package

Tray

USHTS

8542390060

Maximum Overload Pressure

75kPa

PCB changed

4

HTS

8542.39.00.60

Output Type

Wheatstone Bridge

ECCN (US)

EAR99

Port Style

No Port

Supply Voltage - Min

1 V

Supplier Device Package

-

Minimum Operating Temperature (°C)

-40

Maximum Operating Temperature (°C)

125

Accuracy

±1%

Operating Supply Current

6 mA

Output

0 mV ~ 35 mV (3V)

Package Height

29.34(Max)

Mfr

NXP USA Inc.

Features

-

Maximum Operating Temperature

+ 125 C

Supply Voltage - Max

6 V

RoHS Status

ROHS3 Compliant

Mounting Style

Through Hole

Applications

Board Mount

Equivalent Overload Pressure Range (psi)

<20

Package Length

29.85(Max)

Maximum Supply Current (mA)

6(Typ)

Minimum Operating Temperature

- 40 C

Series

MPX10

Operating Supply Voltage

3 V

Part Status

Active

Package Width

11.05(Max)

Maximum Pressure

10.88PSI (75kPa)

Base Product Number

MPX10

Minimum Operating Supply Voltage (V)

1
