EMS22D31-D28-LT2
Sensors
EMS22D31-D28-LT2
54-EMS22D31-D28-LT2
ROTARY ENCODER MAGNETIC 64PPR
In Stock : Please Submit RFQ TO US
Need wholesale pricing? Send RFQ now for the best rates and immediate response.
QUICK RFQ
ADD TO RFQ LIST
Tech Specifications
Unit Weight
0.388014 oz
Product
Magnetic Encoders
Encoder Type
Magnetic
Built in Switch
-
Maximum Operating Speed
10000r/min
Product Status
Active
RoHS
RoHS Compliant By Exemption
Product Length (mm)
15.88
Number of Channels
3
Technology
Magnetic
Voltage - Supply
3.3V
REACH Status
REACH Affected
Typical Operating Supply Voltage
3.3VDC
EU RoHS
Compliant with Exemption
Shaft Style
Plain
Moisture Sensitivity Level (MSL)
1 (Unlimited)
Encoder Signal
Digital Square Wave
Termination Style
PC Pin
Terminal Type
PC Pin
ECCN
EAR99
Maximum Operating Supply Voltage
3.63VDC
Rotational Life (Cycles Min)
50M
Orientation
Vertical
Mounting Type
Panel Mount
Size / Dimension
21 mm x 16 mm
Mounting
Bracket Mount
With Switch
Without Switch
Number of Terminals
6
Bushing Size
3/8 in x 3/8 in
Maximum Operating Torque (N.m)
0.004
SVHC
Yes
Pulses per Revolution
64
HTSUS
8543.70.4500
Package
Tray
USHTS
8543704500
Resolution
64 PPR
Programmability
No
Bushing Thread
3/8-32 UNEF-2A
Output Type
Tachometer
ECCN (US)
EAR99
Minimum Operating Temperature (°C)
-40
Shaft Length
7/8 in
Maximum Operating Temperature (°C)
125
Number of Detents
No Detent
Detent
No
Mfr
Bourns Inc.
Shaft Diameter (mm)
3.18
Product Depth (mm)
21.21
Maximum Operating Temperature
+ 125 C
RoHS Status
ROHS3 Compliant
Encoder Code
Direction/Step
Mounting Style
PCB Mount
Motion
Rotary
Bushing Material
Metal
SVHC Exceeds Threshold
Yes
Shaft Type
Round / Plain
Actuator Type
1/8" Dia Round End
Encoder Reading
Incremental
Shaft Diameter
1/8 in
Minimum Operating Temperature
- 40 C
Series
EMS22D
Type
Non-Contacting Encoder
Body Orientation
Straight
Minimum Operating Supply Voltage
2.97VDC
Operating Supply Voltage
3 VDC
Product Height (mm)
36.12
Base Product Number
EMS22D31
