AS5306A-ATST
54-AS5306A-ATST
ROTARY ENCODER MAGNETIC 1280PPR
In Stock : Please Submit RFQ TO US

Need wholesale pricing? Send RFQ now for the best rates and immediate response.

QUICK RFQ
ADD TO RFQ LIST

Tech Specifications

PCB changed
20
Output Type
Quadrature (Incremental)
ECCN (US)
EAR99
Encoder Type
Magnetic
PPAP
No
Built in Switch
No
Product Status
Obsolete
Automotive
No
Minimum Operating Temperature (°C)
-40
Maximum Operating Temperature (°C)
125
Supplier Package
TSSOP
Minimum Output Voltage (V)
0.5
Voltage - Supply
4.5V ~ 5.5V
Detent
No
REACH Status
REACH Unaffected
Package Height
1
Mfr
ams-OSRAM USA INC.
Maximum Operating Supply Voltage (V)
5.5
EU RoHS
Compliant
RoHS Status
RoHS Compliant
Moisture Sensitivity Level (MSL)
3 (168 Hours)
Termination Style
SMD (SMT) Tab
Actuator Type
External Magnet, Not Included
ECCN
EAR99
Rotational Life (Cycles Min)
-
Package Length
6.5
Supplier Temperature Grade
Extended
Orientation
-
Mounting Type
Surface Mount
Standard Package Name
SO
Pin Count
20
Mounting
Surface Mount
Series
-
Type
Linear|Rotary
Linearity
Yes
Pulses per Revolution
1280
HTSUS
8542.39.0001
Package
Tape & Reel (TR)
Package Width
4.4
Resolution
0.015mm
Base Product Number
AS5306
