ams OSRAM_AS5304A-ATSM
ams OSRAM_AS5304A-ATSM
ams OSRAM

AS5304A-ATSM

Sensors
ams OSRAM
AS5304A-ATSM
54-AS5304A-ATSM
ams OSRAM-AS5304A-ATSM-datasheet-684892.pdf
ams OSRAM-AS5304A-ATSM-datasheets-684892.pdf
ROTARY ENCODER MAGNETIC 1280PPR
In Stock : 1807

Need wholesale pricing? Send RFQ now for the best rates and immediate response.

QUICK RFQ
ADD TO RFQ LIST
ampheo flow
  • Quantity
  • Unit Price
  • Ext. Price
    • 1+
    • $8.30360
    • $8.3
    • 10+
    • $7.18150
    • $71.81
    • 100+
    • $6.73266
    • $673.27
    • 1000+
    • $6.28382
    • $6283.82
    ADD TO CART
    QUICK ORDER
    $8.30360    $8.30
    Description Tech Specifications Documents Shopping Guide

    Tech Specifications

    PCB changed
    20
    HTS
    8542.39.00.60
    Output Type
    Quadrature (Incremental)
    ECCN (US)
    EAR99
    Encoder Type
    Magnetic
    PPAP
    No
    Built in Switch
    No
    Product Status
    Not For New Designs
    Automotive
    No
    Minimum Operating Temperature (°C)
    -40
    Maximum Operating Temperature (°C)
    125
    Supplier Package
    TSSOP
    Minimum Output Voltage (V)
    0.5
    Voltage - Supply
    4.5V ~ 5.5V
    Detent
    No
    REACH Status
    REACH Unaffected
    Package Height
    1
    Mfr
    ams-OSRAM USA INC.
    Maximum Operating Supply Voltage (V)
    5.5
    EU RoHS
    Compliant
    RoHS Status
    RoHS Compliant
    Moisture Sensitivity Level (MSL)
    3 (168 Hours)
    Termination Style
    SMD (SMT) Tab
    Actuator Type
    External Magnet, Not Included
    ECCN
    EAR99
    Rotational Life (Cycles Min)
    -
    Package Length
    6.5
    Supplier Temperature Grade
    Extended
    Orientation
    -
    Mounting Type
    Surface Mount
    Standard Package Name
    SO
    Pin Count
    20
    Mounting
    Surface Mount
    Series
    -
    Type
    Linear|Rotary
    Linearity
    Yes
    Part Status
    Active
    Pulses per Revolution
    1280
    HTSUS
    8542.39.0001
    Package
    Tape & Reel (TR)
    Package Width
    4.4
    Resolution
    0.025mm
    Base Product Number
    AS5304

    AS5304A-ATSM Documents

    Download datasheets and manufacturer documentation for AS5304A-ATSM
