Analog Devices Inc.
ADXRS645HDYZ
Sensors
ADXRS645HDYZ
54-ADXRS645HDYZ
IC GYROSCOPE YAW RATE 32CBGA
In Stock : 33
Need wholesale pricing? Send RFQ now for the best rates and immediate response.
QUICK RFQ
ADD TO RFQ LIST
- 1+
- $1622.68000
- $1622.68
ADD TO CART
QUICK ORDER
$1622.68000
$1622.68
Tech Specifications
Unit Weight
0.054675 oz
PPAP
No
Product Status
Active
RoHS
RoHS Compliant By Exemption
Automotive
No
Supplier Package
CBTIP
Package / Case
15-TRIIP
Technology
MEMS
Sensor Type
1-axis
Voltage - Supply
4.75V ~ 5.25V
REACH Status
REACH Unaffected
Sensitivity (mV/°/s)
1
Sensitivity (LSB/(°/s))
-
Maximum Operating Supply Voltage (V)
5.25
EU RoHS
Compliant with Exemption
Moisture Sensitivity Level (MSL)
1 (Unlimited)
Operating Temperature
-40°C ~ 175°C (TA)
ECCN
7A994
Range
+/- 2000 deg/s
Current - Supply
3.5 mA
Standard Package Name
CTIP
Typical Angular Rate Noise Density (°/s/rtHz)
0.25
Pin Count
15
Typical Angular Velocity (°/s)
±2000
Mounting
Through Hole
Linearity
Yes
Typical Operating Supply Voltage (V)
5
HTSUS
8542.39.0001
Package
Tray
USHTS
8542390060
Typical Sensitivity (mV/°/s)
1
PCB changed
15
HTS
8542.39.00.60
Output Type
Analog Voltage
ECCN (US)
7A994
Typical Bandwidth (Hz)
2000
Shock (g)
10000
Supply Voltage - Min
4.75 V
Minimum Operating Temperature (°C)
-40
Maximum Operating Temperature (°C)
175
Operating Supply Current
3.5 mA
Bandwidth
2kHz
Package Height
9
Mfr
Analog Devices Inc.
Height
3.3 mm
Features
Adjustable Bandwidth, Temperature Sensor
Maximum Operating Temperature
+ 175 C
Supply Voltage - Max
5.25 V
Width
8.2 mm
Axis
X (Pitch) or Y (Roll)
RoHS Status
ROHS3 Compliant
Range °/s
±2000
Mounting Style
Radial
Maximum Operating Supply Current (mA)
3.5(Typ)
Package Length
8
Minimum Operating Temperature
- 55 C
Series
ADXRS645
Type
Analog
Sensitivity
1 mV/deg/s
Length
9.2 mm
Part Status
Active
Sensing Axis
Z
Package Width
2.85
Acceleration
10000 g
Base Product Number
ADXRS645
Minimum Operating Supply Voltage (V)
4.75
