ACZ09BR1E-15FD1-20C
Sensors
ACZ09BR1E-15FD1-20C
54-ACZ09BR1E-15FD1-20C
ROTARY ENCODER INCREMENT 20PPR
In Stock : Please Submit RFQ TO US
Need wholesale pricing? Send RFQ now for the best rates and immediate response.
QUICK RFQ
ADD TO RFQ LIST
Tech Specifications
HTS
8543.70.98.60
Output Type
Quadrature (Incremental)
ECCN (US)
EAR99
Encoder Type
Incremental
PPAP
No
Built in Switch
Yes
Product Status
Active
Automotive
No
Minimum Operating Temperature (°C)
-10
Maximum Operating Temperature (°C)
75
Product Length (mm)
9.5
Number of Channels
2
Voltage - Supply
5V
Detent
Yes
REACH Status
REACH Unaffected
Mfr
CUI Devices
Shaft Diameter (mm)
6
Product Depth (mm)
25.9
EU RoHS
Compliant
Mechanical Life (Cycles)
30000
Shaft Style
Flat
RoHS Status
ROHS3 Compliant
Encoder Code
Quadrature
Moisture Sensitivity Level (MSL)
1 (Unlimited)
Motion
Rotary
Encoder Signal
Digital Square Wave
Termination Style
PC Pin
Actuator Type
6mm Dia Flatted End
Encoder Reading
Incremental
Terminal Type
PC Pin
ECCN
EAR99
Maximum Operating Supply Voltage
5VDC
Rotational Life (Cycles Min)
30K
Orientation
Vertical
Mounting Type
Panel, PCB Through Hole
Mounting
Through Hole
Series
ACZ09
Body Orientation
Straight
Maximum Operating Torque (N.m)
0.02
Product Height (mm)
12.4
Pulses per Revolution
20
HTSUS
8543.70.4500
Package
Box
Programmability
No
Base Product Number
ACZ09BR1
