Integrated Power Designs
1011535
External/Internal DC DC Converters
1011535
50-1011535
DC/DC CNVRTR 3.3V 5V +/-12V 80W
In Stock : 1
Need wholesale pricing? Send RFQ now for the best rates and immediate response.
QUICK RFQ
ADD TO RFQ LIST
- 1+
- $118.79000
- $118.79
- 25+
- $112.45000
- $2811.25
- 100+
- $109.40000
- $10940
ADD TO CART
QUICK ORDER
$118.79000
$118.79
1011535 Description
Open Frame DC DC Converter 4 Output 3.3V 5V 12V -12V 6A, 5A, 2A, 2A 18V Input
Tech Specifications
Voltage - Input (Max)
18V
Product Status
Active
Current - Output (Max)
6A, 5A, 2A, 2A
Voltage - Input (Min)
9V
Efficiency
82%
Mfr
Integrated Power Designs
RoHS Status
ROHS3 Compliant
Moisture Sensitivity Level (MSL)
1 (Unlimited)
Operating Temperature
0°C ~ 70°C (With Derating)
Applications
ITE (Commercial), Medical
Voltage - Output 2
5V
Voltage - Output 3
12V
Voltage - Output 4
-12V
Approval Agency
CE, cURus, TUV, UKCA
ECCN
EAR99
Voltage - Output 1
3.3V
Mounting Type
Chassis Mount
Size / Dimension
4.50" L x 2.50" W x 1.17" H (114.3mm x 63.5mm x 29.7mm)
Number of Outputs
4
Series
DC1-80 (80W)
Power (Watts)
80W
Type
Open Frame
Standard Number
60601-1; 62368-1
HTSUS
8504.40.6007
Package
Box
1011535 Documents
Download datasheets and manufacturer documentation for 1011535
